Telemecanique XCK-J-H29 Limit Switch Head

Telemecanique XCK-J-H29 Limit Switch Head

Product Description

The Telemecanique XCK-J-H29 is a limit switch head component from the XCKJ series, designed for use with compatible XCKJ limit switch bodies. It provides reliable mechanical position detection for industrial machinery by converting mechanical movement into electrical switching signals. The H29 suffix indicates metric M20 cable entry configuration for specific regional versions.

Technical Specifications

• Brand: Telemecanique Sensors / Schneider Electric
• Model: XCK-J-H29
• Product Type: Limit Switch Head
• Series: XCKJ / XC Standard
• Head Type: Mechanical actuator head
• Compatibility: XCKJ series limit switch bodies
• Actuation Type:
  • Plunger type
  • Roller lever type
  • Other actuator options depending on configuration
• Mechanical Operation: Snap-action switching mechanism
• Cable Entry: M20 metric thread (H29 version)
• Mounting: XCKJ limit switch body assembly
• Application: Industrial position detection

Advantages & Features

• Reliable mechanical position sensing
• Durable industrial design for harsh environments
• Easy replacement and maintenance
• Compatible with Telemecanique XCKJ limit switch systems
• Supports flexible actuator configurations
• Improves machine positioning and safety monitoring

Applications

• Industrial automation equipment
• Machine tools
• Conveyor systems
• Packaging machinery
• Material handling equipment
• Production line position detection
• Safety interlock systems

Notes / Precautions

• Confirm compatibility between the head and XCKJ switch body before installation
• Select the correct actuator type according to movement direction
• Check mounting alignment to avoid excessive mechanical stress
• Ensure correct cable entry and sealing protection
• Disconnect power before maintenance or replacement
