TELEMECANIQUE XAC-A481 Pendant Control Station
Item NO.:
XAC-A481Payment:
T/TPrice:
$650Product Origin:
JapanColor:
NEWProduct weight:
0.21KGLead Time:
In stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
Only part of the brand and model, if you have other product needs, please contact us.
The TELEMECANIQUE XAC-A481 is a Harmony XAC pendant control station with a yellow polypropylene enclosure and 4 mechanically interlocked push buttons. It is designed primarily for controlling single-speed hoist motors, with each push button providing 1 NO + 1 NC contact.
| Parameter | Specification |
|---|---|
| Brand | Telemecanique / Schneider Electric |
| Model | XAC-A481 / XACA481 |
| Product Family | Harmony XAC |
| Product Type | Pendant Control Station |
| Application | Single-Speed Hoist Motor Control |
| Number of Push Buttons | 4 |
| Button Functions | Up / Down / Left / Right |
| Contact Configuration | 1 NO + 1 NC per button |
| Mechanical Interlocking | Between button pairs |
| Enclosure Material | Polypropylene |
| Enclosure Color | Yellow |
| Insulation | Double Insulated |
| Connection | Screw Clamp Terminals |
| Protection Rating | IP65 |
| Operating Temperature | -25 to +70°C |
| Standards | EN/IEC 60204-32 |
| Approx. Dimensions | 107 × 80 × 250 mm |
| Approx. Weight | 0.675 kg |
The four buttons are mechanically interlocked in pairs, and Schneider documentation identifies the station as a complete, ready-to-use control station.
