SCHNEIDER ZBVBG1 Pilot Light Module

Product Description

SCHNEIDER ZBVBG1 is a Harmony XB4 / XB5 Series LED Light Module (Pilot Light Module) designed for use with 22 mm diameter push buttons, selector switches, and pilot light heads. It provides visual indication of machine or control system status through an integrated LED light source.

The module uses a universal LED design, supports 24…120V AC/DC supply, and is compatible with Schneider Harmony XB4 and XB5 operator devices.

Specifications

• Brand: SCHNEIDER ELECTRIC
• Model: ZBVBG1
• Series: Harmony XB4 / XB5
• Product Type: Pilot Light Module / LED Light Block
• Module Type: Universal LED illumination module
• Mounting Diameter: 22 mm
• Light Source: LED
• Light Color: White (compatible with different color heads)
• Supply Voltage: 24…120 V AC/DC
• Rated Frequency: 50/60 Hz
• Connection Type: Screw clamp terminals
• Compatible Heads: Harmony XB4 and XB5
• Signaling Mode: Steady light / flashing light
• Protection: Designed for industrial control panel applications

Advantages & Features

• Integrated LED design provides long service life
• Universal voltage range simplifies inventory management
• Compatible with Schneider Harmony XB4 and XB5 series components
• Quick installation and easy replacement
• Clear visual indication of equipment status
• Compact design saves control panel space
• Reliable operation in industrial automation environments

Applications

• Industrial control cabinets
• PLC control panels
• Machine status indication
• Motor control systems
• Automation equipment
• Production lines
• Electrical distribution panels
• Operator interface stations

Notes

• ZBVBG1 is a light module only, not a complete pilot lamp assembly
• Requires a compatible Harmony XB4/XB5 front head/lens
• Confirm supply voltage before installation
• Check terminal wiring before powering on
• Disconnect power before replacement or maintenance
• Ensure compatibility with the selected operator device
