SCHNEIDER ZB2-BE101 Contact Block

SCHNEIDER ZB2-BE101 Contact Block

Product Description

The SCHNEIDER ZB2-BE101 (ZB2BE101) is a Harmony series 22mm push button contact block designed for Schneider Electric control switches and push buttons. It provides a 1 normally open (1NO) contact for transmitting control signals in industrial automation and electrical control circuits. It is commonly used with Harmony XB4/XB5 series push buttons and selector switches.

Technical Specifications

• Brand: Schneider Electric
• Model: ZB2-BE101 / ZB2BE101
• Product Type: Contact Block
• Series: Harmony ZB2 / XB4 / XB5
• Contact Configuration: 1NO (Normally Open)
• Contact Operation: Slow-break
• Mounting Type: Front mounting
• Connection Type: Screw clamp terminals
• Rated Insulation Voltage: 600 V
• Conventional Thermal Current: 10 A
• Contact Rating:
  • AC-15: 3 A at 240 VAC
  • AC-15: 1.2 A at 600 VAC
  • DC-13: 0.27 A at 250 VDC
• Operating Temperature: -25°C to +70°C
• Mechanical Durability: Up to 1,000,000 operations

Advantages & Features

• Original Schneider Harmony contact accessory
• Standard 22mm industrial control component
• Reliable 1NO switching contact
• Screw terminal wiring for easy installation
• Compatible with multiple Schneider operator devices
• Compact design for control panel applications
• High mechanical service life

Applications

• Industrial control panels
• PLC input signal circuits
• Machine start/stop stations
• Motor control systems
• Factory automation equipment
• Electrical cabinets
• Operator control stations

Notes / Precautions

• This is only a contact block, not a complete push button.
• Requires a compatible Schneider Harmony operator head (XB4/XB5/ZB2 series).
• Confirm contact type (1NO) before replacement.
• Check voltage and current requirements of the control circuit before use.
