SCHNEIDER XVLA323 Indicator Light

SCHNEIDER XVLA323 Indicator Light

Product Description

The SCHNEIDER XVLA323 is a Harmony XVL series LED indicator light (pilot light) designed for industrial control panels and machine operator interfaces. It provides visual status indication for equipment operation, alarms, power status, and control signals. The device features a green LED light source, 12V DC operating voltage, and a compact 12 mm mounting design.

Technical Specifications

• Brand: Schneider Electric
• Model: XVLA323
• Product Type: LED Indicator Light / Pilot Light
• Series: Harmony XVL
• Light Color: Green
• Light Source: Integrated LED
• Rated Voltage: 12 VDC
• Current Consumption: 18 mA
• Mounting Diameter: Ø12 mm
• Connection: Screw terminal
• Protection Rating: IP40 (IP65 with sealing accessory XVLZ912)
• Body Material: Plastic
• Operating Temperature: -25°C to +70°C
• Service Life: Approx. 100,000 hours

Advantages & Features

• Schneider Harmony XVL series industrial indicator
• Bright green LED indication with low power consumption
• Compact 12 mm panel mounting design
• High resistance to vibration and industrial environments
• Long LED service life
• Easy installation with screw terminals
• Suitable for PLC control panels and automation equipment

Applications

• Industrial control cabinets
• Machine status indication
• PLC automation systems
• Motor control panels
• Factory production equipment
• Electrical distribution panels
• Building automation systems

Notes / Precautions

• Confirm the supply voltage (12V DC) before installation.
• Ensure the panel cutout size is 12 mm.
• For outdoor or higher protection requirements, use the appropriate sealing accessory.
• This product is an indicator light, not a push button or switch.
