                                          • SCHNEIDER XS112BHNAL2 Inductive Proximity Sensor

                                            Product Overview

                                            The SCHNEIDER XS112BHNAL2 is a Telemecanique Sensors XS1 inductive proximity sensor with an M12 × 1 threaded brass body, NPN normally-open output, 4 mm sensing distance, and a 2 m pre-wired cable. It is designed for non-contact detection of metal objects.

                                            Key Technical Specifications

                                            Parameter	Specification
                                            Brand	Schneider Electric / Telemecanique Sensors
                                            Model	XS112BHNAL2
                                            Product Type	Inductive Proximity Sensor
                                            Series	XS1
                                            Body Size	M12 × 1
                                            Body Length	49 mm
                                            Housing Material	Nickel-Plated Brass
                                            Sensing Distance	4 mm
                                            Mounting	Flush / Shielded
                                            Output Type	NPN
                                            Output Function	1 NO (Normally Open)
                                            Wiring	3-Wire DC
                                            Supply Voltage	12–24 VDC
                                            Switching Capacity	≤ 200 mA
                                            Switching Frequency	≤ 950 Hz
                                            Connection	2 m PVC Cable
                                            Protection Rating	IP67
                                            Status Indicator	Yellow LED
                                            Operating Temperature	-25 to +70°C
                                            Protection	Reverse polarity, overload and short-circuit protection

                                            Specifications are confirmed by the Telemecanique Sensors product page and Schneider catalog.

                                            Advantages & Features

                                            • Compact M12 cylindrical design
                                            • 4 mm sensing distance
                                            • NPN normally-open output
                                            • 12–24 VDC operation
                                            • Fast switching frequency up to 950 Hz
                                            • IP67 protection for industrial environments
                                            • Nickel-plated brass housing
                                            • Built-in reverse-polarity, overload and short-circuit protection

                                            Typical Applications

                                            • Machine automation
                                            • Position and presence detection
                                            • Conveyor systems
                                            • Metal-part detection
                                            • Packaging machinery
                                            • Industrial PLC control systems

                                            Important Precautions

                                            • Confirm that the PLC or controller is compatible with an NPN output.
                                            • Maintain the specified 4 mm sensing distance for reliable detection.
                                            • Verify the 12–24 VDC supply before wiring.
                                            • Avoid mechanical impact on the sensing face and cable.
                                            • Ensure the sensor is correctly mounted flush with the surrounding metalwork.
