SCHNEIDER VX5X60001 Drive Module

Schneider VX5X60001 Drive Module (ATV6000 Service / Power Board)

The Schneider VX5X60001 is a drive service module / internal power electronic board used in Schneider ATV6000 series frequency inverter systems. It is not a complete VFD, but an internal drive module (power or service board) responsible for power conversion and drive control functions inside the inverter.

This type of module is typically used for repair, replacement, or refurbishment of ATV6000 medium-voltage / high-power drive systems.

Key Specifications

• Model: VX5X60001
• Manufacturer: Schneider Electric
• Product Type: Drive Service Board / Power Module
• System: ATV6000 series industrial drive
• Function:
  • Power stage control (IGBT / rectifier interface depending system design)
  • Drive internal signal processing support
• Installation: Internal plug-in / rack-mounted drive section
• Voltage Level: Industrial high-power drive system (application dependent)
• Status: Discontinued / service spare part
• Usage: Repair and maintenance only

Features & Role in System

• Core electronic module inside ATV6000 drive system
• Handles part of power conversion or drive control processing
• Designed for high-power industrial motor control systems
• High-reliability PCB for continuous 24/7 operation
• Used in OEM service replacement scenarios
• Not configurable like PLC modules (no programming interface)

Applications (System Level)

This module is used in drives controlling:

• Large industrial motors
• Heavy-duty pumps and compressors
• Mining / metallurgy equipment
• Oil & gas pumping systems
• Power plant auxiliary systems
• Large conveyor and process lines
