Schneider VW3E1118R020 Encoder Cable

Basic Information

• Model: VW3E1118R020
• Series: VW3E pre-assembled servo encoder feedback cable
• Length: 2 meters (suffix R020 = 2m)
• Connector Type: DB9 male to DB9 male dual-head shielded cable, E-MO-118 wiring standard
• Matching System: Lexium 32 / Lexium 52 servo drives, SH3 / ILM series servo motors with Hiperface encoder interface

Core Technical Parameters

1. Electrical Specs
   • Rated voltage: Max 60VDC / 30VAC low-voltage signal transmission
   • Single pin maximum current: 0.5A
   • Internal structure: Twisted pair signal wiring, full copper braided shielding, double-ended shielding grounding design to suppress EMI/RFI industrial interference
   • Conductor: Tinned copper core, stable signal transmission for SinCos absolute encoder signals
2. Mechanical & Environmental
   • Outer sheath: High-strength PVC industrial jacket
   • Operating temperature range: -20°C ~ +70°C
   • Fixed installation minimum bending radius: 10× cable outer diameter
   • Certification: CE, RoHS compliant
3. Structure Advantage

   Factory pre-terminated finished cable, no on-site soldering required; integrated strain relief at both ends to prevent wire breakage from frequent vibration and pulling

Key Functions

• Transmit Hiperface absolute encoder position, speed and temperature feedback signals between servo drive and servo motor
• Support closed-loop high-precision positioning control, avoid signal loss and position deviation caused by interference
• Complete shielding design adapts to harsh workshop environments with inverters, contactors and strong electromagnetic noise

Application Scenarios

• Packaging machinery, automated assembly lines, printing equipment, textile machinery
• Matching ILM integrated servo motors and SH3 stand-alone servo motors
• Lexium motion control systems with DB9 encoder port wiring layout
• Fixed wiring inside control cabinets and machine frame routing (not designed for drag chain continuous bending use)
