Schneider VBO05S00 PacDrive BT-4/ENC1 Encoder Bus Terminal (Correction: Not Valve Actuator)

Critical Correction

Overview

Core Electrical Specifications

• Model Code: VBO05S00 (BT-4/ENC1)
• Power Supply: 24VDC, operating current 200~1100mA
• Encoder Channels Total: 3
  1. X2/ENC: Master encoder input 1
  2. X3/ENC: Master encoder input 2
  3. X4/INC IO: Configurable incremental encoder input/output
• Interface Type: 15-pin D-Sub encoder ports; X1/X5 terminal blocks for PacNet bus communication
• Weight: 0.79kg, DIN rail cabinet mounting, IP20 protection
• Origin: Germany
• Compatibility: PacDrive3 LMC078, LMC Pro motion controllers

Hardware Interfaces

1. Two independent master encoder ports: Support SSI, EnDat, incremental rotary encoders for main spindle speed & position capture
2. One universal incremental encoder channel: For follower axis, flying shear mark registration, position feedback
3. PacNet bus terminals (X1/X5): Real-time synchronous communication with motion controller, low jitter for multi-axis electronic cam/gearing
4. S1/S2 rotary switches: Station address setting for PacNet bus topology

Key Features

1. Dedicated dual master encoder input design, supports dual-spindle synchronous control
2. High-speed hardware position latch, no signal delay for print mark registration & flying cut
3. PacNet real-time bus, microsecond-level synchronization between axes
4. Metal shielding housing, strong anti-interference for workshop frequency converter & servo noise environment
5. Modular rack installation, plug-and-play with PacDrive control rack
6. Built-in short-circuit protection for encoder wiring faults

Applications

• Printing & converting machinery (flexo, gravure, slitter rewinder)
• High-speed packaging lines, multi-axis carton forming equipment
• Plastic film extrusion, laminating machines
• Textile spinning & warp knitting equipment
• Automated flying shear, continuous cutting synchronous control systems
