• • • • • • • • • • • • • • • • • • • • • • • • SCHNEIDER ELECTRIC TM2AMI4LT Modicon Analog Input Module

                                                Product Overview

                                                The Schneider Electric TM2AMI4LT is a four-channel analog input module designed for compatible Modicon M238, Twido, and Advantys OTB automation systems. It acquires voltage, current, and temperature signals from industrial sensors and converts them into digital values for PLC processing.

                                                Key Technical Specifications

                                                • Brand: Schneider Electric

                                                • Model: TM2AMI4LT

                                                • Product Series: Modicon TM2

                                                • Product Type: Analog Input Module

                                                • Number of Analog Inputs: 4

                                                • Voltage Input Range: 0–10 V DC

                                                • Current Input Range: 0–20 mA

                                                • Supported Temperature Sensors: PT100, PT1000, NI100, NI1000

                                                • PT Sensor Measuring Range: -200°C to +600°C

                                                • NI Sensor Measuring Range: -50°C to +150°C

                                                • Resolution: 12 bits (4096 increments)

                                                • Rated Supply Voltage: 24 V DC

                                                • Supply Voltage Range: 19.2–30 V DC

                                                • Input Impedance: 10 kΩ for voltage; 470 Ω for current

                                                • Sampling Duration: 160 ms

                                                • Connection Type: Removable screw terminal block

                                                • Weight: Approximately 85 g

                                                • Product Status: Discontinued

                                                Key Features

                                                • Four-channel analog signal acquisition.

                                                • Supports voltage, current, and resistance temperature detector (RTD) inputs.

                                                • 12-bit analog-to-digital conversion.

                                                • Compatible with selected Modicon and Twido PLC systems.

                                                • Compact design for industrial control cabinets.

                                                Applications

                                                • Industrial process monitoring

                                                • Temperature measurement

                                                • Pressure and flow monitoring

                                                • PLC-based automation systems

                                                • Manufacturing equipment maintenance and replacement

                                                Important Notes

                                                • All channels must use the same voltage, current, or temperature operating mode; individual temperature sensor types can be configured separately.

                                                • Use shielded cables to reduce electromagnetic interference.

                                                • Verify PLC compatibility, sensor wiring, and software configuration before installation.

                                                • This model is discontinued; confirm availability and product condition before ordering.
