SCHNEIDER TBUX297319 Terminal Block / Connection Module

SCHNEIDER TBUX297319 Terminal Block / Connection Module

Product Description
Schneider Electric TBUX297319 is a SCADAPack 5506 Analog Input Expansion Module used for industrial remote telemetry and automation systems. It provides 8-channel analog input acquisition capability and is designed for connection with SCADAPack RTU controllers for monitoring field signals.

Technical Parameters

• Brand: Schneider Electric
• Model: TBUX297319
• Product Type: Analog Input Expansion Module
• Series: SCADAPack 5506
• Compatible Systems:
  • SCADAPack 47x
  • SCADAPack 57x
  • SCADAPack 500E
  • SCADAPack 300E
• Analog Input Channels: 8 AI
• Input Types:
  • 0–5 V DC
  • 1–5 V DC
  • 0–20 mA
  • 4–20 mA
• Application: Remote I/O expansion and telemetry data acquisition
• Installation: SCADAPack RTU expansion system
• Product Weight: Approx. 0.5 kg
• Certifications: ATEX / IECEx / Hazardous Area certifications (depending on configuration)

Advantages & Features

• Original Schneider Electric SCADAPack expansion module
• Provides 8-channel analog signal acquisition
• Supports common industrial voltage and current signals
• Improves RTU system monitoring capability
• Reliable data acquisition for remote applications
• Suitable for harsh industrial environments
• Flexible expansion for SCADAPack control systems

Applications

• Industrial telemetry systems
• Oil & gas monitoring
• Water treatment systems
• Power distribution monitoring
• Remote control stations
• Process automation systems
• SCADA systems

Notes

• Confirm compatibility with the SCADAPack controller before installation.
• Check analog input signal type before wiring.
• Ensure correct power supply and grounding.
• Verify configuration parameters after replacement.
• Follow proper electrical safety procedures during installation.
