Schneider SXWASB24X10001 SpaceLogic AS-B-24 Controller (SmartX Sensor Bus Main Controller)

Overview

Specifications

• Model: SXWASB24X10001 (AS-B-24, screenless version)
• Total 24 mixed onboard I/O points: universal analog/digital inputs, relay outputs, solid-state outputs
• Built-in dedicated SmartX sensor bus (RJ45 bus) to power & communicate with SmartX room touch sensors
• Communication: Dual Ethernet BACnet/IP, RS485 BACnet MS/TP, Modbus RTU, USB local commissioning port
• Memory: 256MB RAM + 4GB local storage for trend logs, alarms and scheduling
• Power supply: 24V DC / 230V AC optional built-in power supply
• Mounting: Standard 35mm DIN rail, IP20 cabinet housing
• Dimension: W198 × H110 × D64 mm
• Operating temperature: 0 ~ 50℃, 95%RH non-condensing
• Compliance: CE, RoHS, UL building automation certification

Core Features

1. Dedicated SmartX sensor bus: One cable supplies power and data to room temperature/humidity/CO₂ touch panels, simplifies wiring
2. Standalone & network dual operation: Runs control logic independently when network disconnected, supports alarm logging & trend recording
3. Rich protocol interconnection: Connects RP-C room controllers, IP-I/O expansion modules, Zigbee wireless adapters
4. Programmable via EcoStruxure Building Operation software, supports customized CFC control logic for HVAC, lighting, pump groups
5. USB local commissioning, no extra software required for basic parameter upload/download
6. Expandable I/O capacity via SpaceLogic IP-IO modules for large equipment room control demands
