SCHNEIDER SH31403P02F2000 Servo Motor

SCHNEIDER SH31403P02F2000 Servo Motor

Product Description

The SCHNEIDER SH31403P02F2000 is a Lexium SH3 AC servo motor designed for high-performance motion control applications. It is part of the PacDrive 3 / Lexium SH3 servo motor family and features a 140 mm flange size, 27.8 Nm continuous stall torque, absolute multiturn SinCos encoder, and integrated holding brake. It provides high torque output, precise positioning, and reliable performance for demanding industrial automation systems.

Technical Specifications

• Brand: Schneider Electric
• Model: SH31403P02F2000
• Product Type: AC Servo Motor
• Series: Lexium SH3 / PacDrive 3
• Motor Size: SH3 140 (140 mm flange)
• Rated Voltage: 115–480 VAC, 3-phase
• Continuous Stall Torque: 27.8 Nm
• Peak Torque: Approx. 90.2 Nm
• Continuous Power: Approx. 4.1 kW
• Maximum Speed: 4000 rpm
• Encoder Type: Absolute multiturn SinCos Hiperface encoder
• Encoder Resolution: 128 periods
• Shaft Type: Smooth shaft (without key)
• Shaft Diameter: 24 mm
• Holding Brake: With brake
• Holding Torque: Approx. 36 Nm
• Connector: 90° angled M40/M23 connectors
• Protection Rating: IP54 / IP65

Advantages & Features

• High torque density for heavy-duty motion applications
• Integrated holding brake for vertical-axis and load-holding applications
• Absolute multiturn encoder provides accurate position feedback without repeated homing
• Low inertia design for fast acceleration and deceleration
• High overload capability for demanding automation tasks
• Compatible with Schneider Lexium and PacDrive 3 motion control systems

Applications

• Industrial robotics
• Packaging machinery
• CNC equipment
• Material handling systems
• Automated production lines
• Heavy-duty positioning systems
• Precision motion control equipment

Notes / Precautions

• Requires a compatible Schneider Lexium servo drive for operation.
• Confirm encoder type, brake wiring, and motor parameters before installation.
• Verify flange size, shaft dimensions, and connector type before replacement.
• This is a servo motor, not a standard AC induction motor.
