SCHNEIDER SH31003P12F2000 Lexium Servo Motor
Item NO.:
SH31003P12F2000Payment:
T/TPrice:
$650Product Origin:
JapanColor:
NEWProduct weight:
0.21KGLead Time:
In stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
Only part of the brand and model, if you have other product needs, please contact us.
|
Parameter |
Specification |
|---|---|
|
Brand |
Schneider Electric |
|
Model |
SH31003P12F2000 |
|
Product Series |
SH3 100 |
|
Product Type |
AC Servo Motor |
|
Compatible Platform |
PacDrive 3 |
|
Rated Supply Voltage |
115–480 V AC, three-phase |
|
Continuous Stall Torque |
8 Nm |
|
Peak Stall Torque |
28.3 Nm |
|
Maximum Mechanical Speed |
6,000 rpm |
|
Rated Power |
Up to 2.56 kW, depending on voltage |
|
Encoder |
Absolute multiturn SinCos Hiperface |
|
Holding Brake |
Integrated |
|
Holding Brake Torque |
9 Nm |
|
Shaft Type |
Parallel keyed shaft |
|
Flange Size |
100 mm |
|
Protection Rating |
IP65 motor; IP54 at shaft bushing without shaft seal |
|
Electrical Connection |
Rotatable right-angle connector |
Manufacturer specifications:
High-Precision Motion Control: Supports accurate positioning and speed regulation.
High Peak Torque: Provides 28.3 Nm peak stall torque for demanding dynamic applications.
Multiturn Feedback: Absolute encoder supports position feedback across multiple revolutions.
Integrated Holding Brake: Helps maintain the motor shaft position when properly applied.
Industrial Protection: IP65 motor protection for suitable industrial environments.
Packaging and processing machinery
Automated production lines
Robotics and material handling
Precision positioning systems
Industrial machine tools
High-performance motion control systems
Verify compatibility with the servo drive, encoder interface, voltage, and motor cables before installation.
The rated power and speed depend on the supply voltage and operating conditions.
The holding brake is intended for holding, not routine dynamic stopping.
Check the shaft dimensions, connector orientation, and brake specifications before ordering.
