Product Description

The SCHNEIDER SH30702P02A2000 is a Lexium SH3 AC servo motor designed for high-performance motion control applications. It is part of the PacDrive 3 / Lexium SH3 servo motor family, featuring a 70 mm flange size, 2.1 Nm rated torque, absolute multiturn SinCos encoder, and no holding brake design. It provides precise positioning, fast response, and reliable operation for industrial automation systems.

Technical Specifications

• Brand: Schneider Electric
• Model: SH30702P02A2000
• Product Type: AC Servo Motor
• Series: Lexium SH3 / PacDrive 3
• Motor Size: 070 (70 mm flange)
• Rated Torque: Approx. 2.1 Nm
• Continuous Stall Torque: 2.2 Nm
• Peak Torque: 7.6 Nm
• Rated Voltage: 115–480 VAC, 3-phase
• Maximum Speed: 8000 rpm
• Rated Speed: Up to 7200 rpm (depending on voltage)
• Rated Power: Approx. 1.1 kW (480V)
• Encoder Type: Absolute multiturn SinCos Hiperface encoder
• Encoder Resolution: 128 periods
• Shaft Type: Smooth shaft (without key)
• Shaft Diameter: 11 mm
• Brake: Without brake
• Connector: 90° angled M23 connectors
• Protection Rating: IP54/IP65

Advantages & Features

• High-precision servo positioning capability
• Compact 70 mm flange design for machine integration
• Absolute multiturn encoder eliminates repeated homing after power loss
• High overload capability for dynamic motion applications
• Low inertia design for fast acceleration and deceleration
• Compatible with Schneider Lexium and PacDrive motion control systems

Applications

• Packaging machinery
• Robotics and automation equipment
• CNC machines
• Material handling systems
• Assembly lines
• Precision motion control systems
• Industrial production equipment

Notes / Precautions

• Requires a compatible Schneider Lexium servo drive for operation.
• Confirm encoder type, motor parameters, and drive compatibility before installation.
• This model does not include an integrated holding brake.
• Verify flange size, shaft dimensions, and connector type before replacement.
