- - Schneider NW32H1

    MasterPact NW32H1 Air Circuit Breaker (ACB)

    Series: MasterPact NW

    Type: 3200A Air Circuit Breaker (fixed frame, without control unit)

    P/N: NW32H1 (SKU: 48082)

    Basic Information

    Manufacturer: Schneider Electric

    Rated current (In): 3200 A (40°C)

    Poles: 3P (4P available as NW32H1 48087)

    Mounting: Fixed (draw-out optional)

    Application: Low-voltage main distribution, industrial plants, data centers

    Standard: IEC 60947-2, UL 1066

    Technical Specifications

    Rated operational voltage (Ue): 690 V AC 50/60 Hz

    Rated insulation voltage (Ui): 1000 V AC

    Impulse withstand voltage (Uimp): 12 kV

    Ultimate breaking capacity (Icu): 65 kA @ 440 V AC

    Service breaking capacity (Ics): 100% Icu

    Short-time withstand (Icw): 65 kA / 1 s

    Making capacity (Icm): 143 kA @ 525 V AC

    Protection class: Category B (selective protection)

    Mechanical life: 10,000 cycles (maintenance-free)

    Key Features

    High breaking capacity: 65 kA for heavy fault current handling

    Wide voltage range: Up to 690 V AC for versatile distribution systems

    Robust frame design: Fixed-type frame, compatible with Micrologic trip units

    Isolation capability: Suitable for isolation per IEC 60947-2

    Durability: Designed for long-term industrial use
