SCHNEIDER NTSPFB1002HK Fieldbus Module

Schneider NTSPFB1002HK Fieldbus Module (Modicon Edge I/O NTS Power & Bus Module Kit)





The Schneider NTSPFB1002HK is not a simple communication module. It is a Modicon Edge I/O NTS power supply + base module kit that provides both bus power and field power distribution for a distributed I/O system.

In Schneider’s Edge I/O NTS architecture, this module acts as the power backbone of the I/O station, supplying and managing power for:

• Network interface modules
• Field I/O modules
• Bus communication system

Key Specifications

• Model: NTSPFB1002HK
• Series: Modicon Edge I/O NTS
• Product Type: Power Supply Module + Base (Bus & Field Power Unit)
• Input Voltage: 24 V DC
• Function:
  • Supplies bus power (controller / network interface)
  • Supplies field power (I/O modules / loads)
• Output Distribution:
  • Bus supply (approx. 3.5 A class)
  • Field supply (up to approx. 10.5 A class, system dependent)
• Mounting: DIN rail
• Design: Hardened industrial version (conformal coating)
• Feature: Hot-swappable modular design
• Operating Temperature: wide industrial range (approx. -40°C to +70°C)
• Protection: IP20

Features & Advantages

• Acts as central power hub for Edge I/O system
• Separates bus power and field power for stability
• Supports hot-swap replacement (reduces downtime)
• Hardened design for harsh environments
• DIN rail modular installation (fast system expansion)
• Improves system reliability and scalability
• Designed for IIoT / distributed automation architecture

Applications

• Distributed I/O automation systems
• Industrial machine control panels
• Packaging and production lines
• Factory automation and smart manufacturing
• Process control systems
• Edge computing + IIoT architectures
