SCHNEIDER NTSAMI0210HK Analog Input Module

Schneider NTSAMI0210HK Analog Input Module (Modicon Edge I/O NTS)





The Schneider NTSAMI0210HK is a Modicon Edge I/O NTS analog input module kit, used in distributed industrial automation systems. It is designed to collect and convert analog signals (current and voltage) from field instruments into digital data for a PLC or controller via the Edge I/O network.

This module is part of Schneider’s Edge I/O NTS system, and the “HK” version is a pre-assembled kit (base + module).

Key Specifications

• Model: NTSAMI0210HK
• Series: Modicon Edge I/O NTS
• Product Type: Analog Input Module (Kit version)
• Input Channels: 2 isolated analog inputs
• Signal Types Supported:
  • Voltage: ±10V, 0–10V, ±5V, 0–5V, 1–5V
  • Current: 0–20 mA, 4–20 mA, ±20 mA
• Wiring Types: 2-wire / 3-wire / 4-wire sensors supported
• Loop Power: Supported (for transmitter power supply)
• Resolution: High-resolution industrial ADC (exact bit depth depends system configuration)
• Isolation: Channel isolation for noise protection
• Response Time: Fast industrial sampling (sub-millisecond range in system context)
• Mounting: DIN rail
• Protection: IP20, hardened industrial design
• Operating Temperature: approx. -40°C to +70°C

Features & Advantages

• Reads industry standard analog signals (4–20mA / 0–10V)
• 2 isolated channels reduce noise and ground loop issues
• Supports multiple wiring types (2/3/4-wire transmitters)
• Built-in loop power for field instruments
• Modular “Edge I/O” architecture for easy expansion
• High reliability for harsh industrial environments
• Diagnostic capability for signal faults
• Plug-in kit design (base + module)

Applications

• Pressure transmitters (4–20 mA)
• Temperature sensors (RTD/transmitters via converter)
• Flow / level measurement systems
• Industrial process automation
• Packaging and machine control systems
• Energy monitoring systems
• Distributed IIoT sensor networks
