• • • • • • • • • • • • • • • • • • SCHNEIDER NSYS3D4420P Spacial S3D Electrical Enclosure

                                    Specification	Details
                                    Brand	Schneider Electric
                                    Model	NSYS3D4420P
                                    Product Name	Spacial S3D Electrical Enclosure
                                    Product Type	Wall-Mounted Steel Enclosure
                                    Series	Spacial S3D / PanelSeT S3D
                                    Application	Multi-purpose
                                    Material	Steel enclosure; galvanized steel mounting plate
                                    Height	400 mm
                                    Width	400 mm
                                    Depth	200 mm
                                    Door Type	Plain / solid door
                                    Mounting Plate	Included
                                    Cable Gland Plate	Standard, included
                                    Door Opening	Reversible, 120°
                                    Lock	3 mm double-bar lock
                                    Color	Gray, RAL 7035
                                    Surface Finish	Epoxy-polyester powder coating
                                    Protection Rating	IP66
                                    Impact Resistance	IK10
                                    Standards	IEC 62208
                                    Certifications	UL, cUL, DNV, GL, BV
                                    Mounting	Wall mounting
                                    Net Weight	Approx. 8 kg

                                    Key Technical Specifications

                                    • 400 × 400 × 200 mm enclosure size

                                    • Steel construction with galvanized steel mounting plate

                                    • Plain reversible door with 120° opening

                                    • IP66 protection according to IEC 60529

                                    • IK10 mechanical impact resistance

                                    • 3 mm double-bar locking system

                                    • RAL 7035 light gray epoxy-polyester finish

                                    • Includes body, door with lock, mounting plate and cable gland plate

                                    Advantages & Features

                                    • Rugged steel construction for industrial environments

                                    • High protection against dust and water

                                    • High mechanical impact resistance

                                    • Integrated mounting plate simplifies installation of electrical components

                                    • Reversible door provides flexible cabinet access

                                    • Suitable for a wide range of industrial control applications

                                    Applications

                                    • Industrial control panels

                                    • PLC and automation equipment

                                    • Electrical distribution

                                    • Motor control systems

                                    • Machine control cabinets

                                    • Factory automation and instrumentation

                                    Precautions

                                    • Verify enclosure dimensions and mounting requirements before installation.

                                    • Maintain appropriate cable gland sealing to preserve the IP66 rating.

                                    • Ensure proper grounding and bonding of the metal enclosure.

                                    • Confirm the internal mounting plate arrangement before installing equipment.

                                    • Avoid drilling or modifying the enclosure in ways that may compromise its protection rating.
