SCHNEIDER NSYCCOTHO ClimaSys CC Enclosure Accessory

Product Overview

The SCHNEIDER NSYCCOTHO is a ClimaSys CC simple thermostat accessory designed for Schneider Electric electrical enclosures and control cabinets. It is used for temperature monitoring and ventilation control, helping maintain a suitable internal cabinet temperature and protecting sensitive electrical components.

The thermostat uses a bimetal temperature sensor with a normally open (NO) contact, suitable for controlling enclosure fans or cooling devices.

Technical Specifications

• Brand: SCHNEIDER ELECTRIC
• Model: NSYCCOTHO
• Series: ClimaSys CC
• Type: Enclosure Thermostat / Cabinet Temperature Controller
• Contact Type: Normally Open (NO)
• Sensor Type: Bimetal sensor
• Temperature Setting Range: 0…60 °C
• Rated Voltage: 250 V AC
• Maximum Switching Capacity:
  • 10 A at 250 V AC (resistive load)
  • 2 A at 120…250 V AC (inductive load)
  • 30 W DC
• Electrical Connection: 4 terminals, 2.5 mm²
• Mounting: Clip-on mounting
• Installation: 35 mm DIN rail / mounting plate
• Protection Rating: IP20
• Dimensions: Approx. 68 × 33 × 44 mm
• Weight: Approx. 40 g

Advantages & Features

• Original Schneider Electric ClimaSys accessory
• Provides reliable temperature monitoring inside electrical enclosures
• Simple NO contact design for fan or cooling control
• Compact size for easy cabinet installation
• Improves thermal management of control cabinets
• Helps prevent overheating of electrical components
• Long mechanical service life
• Compatible with Schneider Spacial enclosure systems

Applications

• Electrical control cabinets
• Industrial automation panels
• PLC cabinets
• Power distribution enclosures
• Motor control centers
• Network and communication cabinets
• Factory automation systems
• Industrial equipment cooling systems

Precautions

• Confirm thermostat contact type before installation
• Check operating temperature requirements
• Ensure correct wiring and terminal connection
• Do not exceed rated switching current
• Install in a location with accurate cabinet temperature detection
• Ensure ventilation equipment matches thermostat specifications
• Disconnect power before installation or maintenance
