SCHNEIDER MS51-7103-150 Control Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

• • • • • • • • • • SCHNEIDER MS51-7103-150 SmartX Linear Actuator

                    Important correction: The SCHNEIDER MS51-7103-150 is not a Control Module. It is a SmartX proportional spring-return valve actuator for building automation/HVAC applications. Schneider documentation identifies it as a 105 lbf (467 N) linear actuator with 0–10 VDC proportional control and 24 VAC/VDC power.

                    Key Technical Specifications

                    Parameter	Specification
                    Brand	Schneider Electric
                    Model	MS51-7103-150
                    Product Type	SmartX Linear Valve Actuator
                    Actuator Type	Proportional, Spring Return
                    Control Signal	0–10 VDC
                    Power Supply	24 VAC ±20% / 20–30 VDC
                    Output Force	105 lbf / 467 N
                    Linear Stroke	1/2 in / 13 mm
                    Feedback Signal	2–10 VDC
                    Running Power	Approx. 4.2 W
                    Running Current	Approx. 0.14 A DC
                    Holding Power	Approx. 1.5 W
                    Cable	3 ft Plenum Cable
                    Enclosure	NEMA 2
                    Motor Type	Brush DC Motor
                    Action	Direct / Reverse Acting Selectable
                    Manual Override	Yes
                    Application	Valve Actuation / HVAC
                    Compatible Valve Series	VB7000 Series and VB9000 Series

                    Schneider's technical documentation lists the MS51-7103-150 under the MS51-7103 proportional spring-return actuators, with 0–10 VDC control, 24 VAC/VDC power, 105 lbf output force and 13 mm nominal stroke.

                    Advantages & Features

                    • 105 lbf / 467 N linear output force
                    • 0–10 VDC proportional control
                    • 24 VAC/VDC power supply
                    • Spring-return fail-safe operation
                    • 13 mm linear stroke
                    • Direct/reverse acting selection
                    • Manual override for valve positioning
                    • Position feedback output
                    • Designed for Schneider SmartX/VB valve systems
                    • Suitable for HVAC and building automation

                    Typical Applications

                    • HVAC valve control
                    • Heating and cooling systems
                    • Chilled-water systems
                    • Hot-water control
                    • Building automation systems
                    • Air-handling units
                    • Commercial HVAC installations
                    • Smart building control systems
