SCHNEIDER METSEDM6000 Power Meter Energy Meter

SCHNEIDER METSEDM6000 Power Meter / Energy Meter

Product Description
Schneider Electric METSEDM6000 is an EasyLogic DM6000 digital power meter designed for basic electrical measurement and monitoring applications. It provides measurement of voltage, current, frequency, power factor, phase unbalance, and other electrical parameters, making it suitable for industrial power monitoring and panel instrumentation.

Technical Parameters

• Brand: Schneider Electric
• Model: METSEDM6000
• Product Type: Digital Power Meter / Energy Meter
• Series: EasyLogic DM6000
• Device Type: Digital panel meter
• Measurement Functions:
  • Voltage
  • Current
  • Frequency
  • Power factor
  • Phase unbalance
  • Phase angle
  • RPM (generator applications)
• Rated Supply Voltage: 44…277 V AC 50/60 Hz; 44…277 V DC
• Measurement Voltage: 80…480 V AC phase-to-phase
• Current Input: 1A / 5A CT input
• Measurement Current Range: 0.05…6A
• Accuracy:
  • Voltage: ±1%
  • Current: ±1%
  • Frequency: ±0.1%
  • Power Factor: ±1%
• Display Type: LED digital display
• Communication: No communication interface (basic version)
• Installation: Panel mounting
• Protection: Front display IP51 (with optional gasket IP54), meter body IP30
• Dimensions: 96 × 96 × 49 mm

Advantages & Features

• Original Schneider Electric EasyLogic power monitoring device
• Compact 96×96 panel mounting design
• Clear LED display for easy reading
• Supports multiple electrical parameter measurements
• Suitable for replacing traditional analog meters
• Reliable monitoring for industrial electrical systems
• Simple installation and configuration through front panel keys
• Designed for cost-effective power monitoring applications

Applications

• Industrial control cabinets
• Power distribution panels
• Factory electrical monitoring systems
• Building energy monitoring
• Motor control centers (MCC)
• Generator monitoring systems
• Automation equipment power measurement

Notes

• METSEDM6000 is the basic DM6000 model without communication function.
• Confirm CT ratio (1A/5A) before installation.
• Check voltage range and wiring configuration before use.
• Ensure correct phase sequence and grounding.
• For remote communication requirements, select a model with communication function such as the DM6200 series.
