SCHNEIDER LXM62DD45C21000 Servo Drive

SCHNEIDER LXM62DD45C21000 Servo Drive

Product Description

The SCHNEIDER LXM62DD45C21000 is a Lexium 62 single-axis servo drive from the PacDrive 3 motion control platform. It is designed for high-performance industrial motion applications, providing precise control of servo motors with high current capability. The drive supports Schneider SH3, SHS, and MH3 servo motor series and is suitable for multi-axis automation systems.

Technical Specifications

• Brand: Schneider Electric
• Model: LXM62DD45C21000
• Product Type: Servo Drive / Single Drive
• Series: Lexium 62
• Platform: PacDrive 3
• Drive Type: Single-axis servo drive
• Rated Supply Voltage: 250–700 VDC (DC bus)
• Continuous Output Current: 20 A
• Peak Output Current: 45 A (3s)
• Continuous Power: Approx. 9.6 kW
• Communication Interface: SERCOS III
• Safety Function: STO (Safe Torque Off)
• Protection Rating: IP20
• Motor Compatibility: SH3 / SHS / MH3 servo motors

Advantages & Features

• High-performance single-axis servo control
• High current output for powerful servo motors
• Compact modular design for multi-axis systems
• Supports precise position, speed, and torque control
• Integrated safety functions for industrial machinery
• Simplified wiring and cabinet installation
• Compatible with Schneider PacDrive 3 automation architecture

Applications

• Industrial robotics
• Packaging machinery
• CNC equipment
• Automated production lines
• Material handling systems
• High-precision motion control equipment
• Machine automation systems

Notes / Precautions

• Requires a compatible PacDrive 3 controller and power supply system.
• Confirm servo motor model, encoder feedback, and parameter settings before replacement.
• Ensure correct DC bus voltage and wiring configuration.
• This is a servo drive module, not a standalone inverter.
