Schneider LXM52DD30C41000 Lexium Servo Drive

Product Overview

The Schneider Electric LXM52DD30C41000 is a Lexium 52 single-axis servo drive designed for the PacDrive 3 automation platform. It provides precise motion control for compatible SH3 and MH3 servo motors and communicates through SERCOS III.

Technical Specifications

The drive supports 208–480 VAC three-phase input and provides 10 A continuous current with 30 A peak current for short-duration acceleration or overload conditions.

Advantages & Features

• High-precision motion control for demanding industrial applications.
• 3 kW rated power with 10 A continuous and 30 A peak output capability.
• SERCOS III communication enables fast and reliable synchronization with PacDrive automation systems.
• Integrated 3-phase power supply simplifies system configuration and wiring.
• Built-in digital I/O and touch probe inputs provide flexible machine-control integration.
• Compact design and high power density help save cabinet space.
• Supports overload operation for dynamic acceleration and deceleration.
• Designed for use with Lexium SH3 and MH3 servo motors.
• The Lexium 52 platform incorporates integrated safety functions, including STO functionality.

Typical Applications

• Packaging machinery
• Material handling equipment
• Conveyor and positioning systems
• Printing and labeling machines
• Automated production lines
• Pick-and-place equipment
• Machine tools
• Robotics and precision motion systems
• General industrial automation

Important Notes

• Verify that the input voltage, motor rating, and current requirements match the drive before installation.
• Use only compatible Lexium SH3/MH3 servo motors and appropriate cables/accessories.
• Proper grounding, shielding, and EMC practices are required for reliable operation.
• The unit operates with hazardous high voltage; installation and maintenance should be performed by qualified personnel.
• Ensure adequate cabinet ventilation and observe the specified environmental conditions.
• IP20 means the drive is intended for installation inside a suitable electrical enclosure.
• Follow Schneider Electric installation, wiring, safety, and commissioning instructions befo
