SCHNEIDER LRD365 Overload Relay
Item NO.:
LRD365Payment:
T/TPrice:
$650Product Origin:
JapanColor:
NEWProduct weight:
0.21KGLead Time:
In stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
Only part of the brand and model, if you have other product needs, please contact us.
The SCHNEIDER LRD365 is a TeSys Deca differential thermal overload relay for AC motor protection. It has an adjustable 48–65 A thermal protection range and Class 10A trip characteristic. It is designed to work with compatible TeSys D contactors, particularly the LC1D50A/LC1D65A range.
| Parameter | Specification |
|---|---|
| Brand | Schneider Electric |
| Model | LRD365 |
| Product Family | TeSys Deca / TeSys LRD |
| Product Type | Differential Thermal Overload Relay |
| Application | Motor Protection |
| Adjustment Range | 48–65 A |
| Trip Class | Class 10A |
| Rated Operational Voltage | Up to 690 VAC |
| Frequency | 0–400 Hz |
| Auxiliary Contacts | 1 NO + 1 NC |
| Phase Failure Protection | Yes |
| Temperature Compensation | -20 to +60°C |
| Rated Insulation Voltage | 690 VAC |
| Impulse Withstand | 6 kV |
| Mounting | Under contactor / DIN rail / plate with accessories |
| Dimensions | Approx. 70 × 55 × 123 mm |
| Weight | Approx. 0.375 kg |
Schneider specifies a 1.14 ± 0.06 Ir tripping threshold and phase-failure sensitivity, with the relay tripping at approximately 130% of Ir on two phases when the third phase is at zero.
