SCHNEIDER LR97D25M7 Electronic Overload Relay
Item NO.:
LR97D25M7Payment:
T/TPrice:
$650Product Origin:
JapanColor:
NEWProduct weight:
0.21KGLead Time:
In stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
Only part of the brand and model, if you have other product needs, please contact us.
The SCHNEIDER LR97D25M7 is a TeSys LR97D electronic overcurrent/overload relay designed for motor protection. It operates from 200–240 VAC and provides an adjustable protection range of 5–25 A. Schneider specifies protection against overload, locked rotor/mechanical jamming, and phase failure.
| Parameter | Specification |
|---|---|
| Brand | Schneider Electric |
| Model | LR97D25M7 |
| Product Family | TeSys LR97D |
| Product Type | Electronic Overload / Overcurrent Relay |
| Motor Current Range | 5–25 A |
| Recommended Motor Protection Range | 5–21 A |
| Supply Voltage | 200–240 VAC |
| Frequency | 50/60 Hz |
| Rated Operational Voltage | Up to 690 VAC |
| Protection Functions | Overload, locked rotor/mechanical jamming, phase failure |
| Auxiliary Contacts | 1 NO + 1 NC |
| Thermal Adjustment | 5–25 A |
| O-TIME Adjustment | 0.3–10 s |
| D-TIME Adjustment | 0.5–30 s |
| Mounting | Direct on compatible contactor or rail |
| Width | Approx. 45 mm |
| Connection | Screw-clamp terminals |
The relay is designed for direct connection to compatible TeSys contactors, including the LC1D09–LC1D38 range. Schneider highlights its compact 45 mm width and three adjustment controls.
The LR97D uses electronic monitoring rather than a conventional bimetal thermal element, allowing adjustable timing and protection parameters.
