• • • • • • SCHNEIDER LR97D015M7 TeSys LR97D Electronic Overload Relay

            The SCHNEIDER LR97D015M7 is a TeSys LR97D electronic overcurrent/overload relay for motor protection. It has a 0.3–1.5 A adjustable protection range and a 200–240 VAC control supply. Schneider specifies a usable motor-current range of approximately 0.3–1.3 A for this model.

            Key Technical Specifications

            Parameter	Specification
            Brand	Schneider Electric
            Model	LR97D015M7
            Product Family	TeSys LR97D
            Product Type	Electronic Overload / Overcurrent Relay
            Adjustment Range	0.3–1.5 A
            Usable Motor Range	0.3–1.3 A
            Supply Voltage	200–240 VAC
            Frequency	50/60 Hz
            Rated Phase-to-Phase Voltage	Up to 690 VAC
            Auxiliary Contacts	1 NO + 1 NC
            Overload Protection	Electronic
            Locked-Rotor Protection	Yes
            Phase-Failure Sensitivity	Yes
            O-TIME Setting	0.3–10 s
            D-TIME Setting	0.5–30 s
            Width	Approx. 45 mm
            Mounting	Directly on compatible contactor / DIN rail accessory
            Compatible Contactors	TeSys LC1D09–LC1D38

            Schneider specifies three adjustment dials, a compact 45 mm housing, and settings that can be secured by sealing the transparent cover.

            Advantages & Features

            • Precise electronic motor-current monitoring
            • Adjustable 0.3–1.5 A setting range
            • Protection against motor overload
            • Locked-rotor/mechanical-jamming protection
            • Phase-failure sensitivity
            • 1NO + 1NC auxiliary contacts
            • Compact 45 mm design
            • Three front adjustment controls
            • Settings can be locked to prevent unauthorized adjustment

            Typical Applications

            • Small industrial motors
            • Pumps
            • Fans and blowers
            • Conveyors
            • Compressors
            • Machine tools
            • Motor starter panels
            • Factory automation equipment

            Important Precautions

            • Verify the motor's rated current before adjusting the relay.
            • Do not confuse the 0.3–1.5 A adjustment range with the usable motor range; Schneider documentation specifies approximately 0.3–1.3 A usable range.
            • Confirm the 200–240 VAC supply voltage.
            • Check compatibility with the installed TeSys contactor.
            • Configure the O-TIME and D-TIME settings according to the motor starting characteristics.
            • The relay provides motor overcurrent protection; appropriate short-circuit protection is still required.
