SCHNEIDER LC1G5004EHEA TeSys Giga Contactor
Item NO.:
LC1G5004EHEAPayment:
T/TPrice:
$650Product Origin:
JapanColor:
NEWProduct weight:
0.21KGLead Time:
In stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
Only part of the brand and model, if you have other product needs, please contact us.
Brand: Schneider Electric
Model: LC1G5004EHEA
Product Name: TeSys Giga High-Power Contactor
Product Type: 4-Pole Contactor
Series: TeSys Giga
Version: Advanced
| Key Technical Specification | Details |
|---|---|
| Product Type | High-Power Contactor |
| Series | TeSys Giga |
| Poles | 4P |
| Contact Configuration | 4 NO |
| Utilization Category | AC-1 |
| Rated Operational Current | 700 A at ≤440 V AC |
| Rated Operational Voltage | Up to 1000 V AC |
| Rated Insulation Voltage | 1000 V |
| Control Circuit Voltage | 48–130 V AC/DC |
| Control Technology | Electronic Coil |
| Auxiliary Contacts | 1 NO + 1 NC |
| Rated Impulse Withstand Voltage | 8 kV |
| Conventional Thermal Current | 700 A at 40°C |
| Rated Making Capacity | Up to 10 × Ie |
| Mounting | Panel / Plate Mount |
| Connection | Bolted Power Connections |
| Control Connections | Spring Terminals |
| Operating Temperature | -25 to +60°C |
| Protection | IP2x front protection with shrouds |
| Mechanical Durability | Up to 5 million cycles |
| Product Version | Advanced |
| Application | High-Current AC Switching |
High-power TeSys Giga contactor for demanding industrial applications
4 normally-open power poles
High AC-1 current rating of 700 A at ≤440 V
Wide-range 48–130 V AC/DC electronic coil
Integrated 1 NO + 1 NC auxiliary contact
Advanced version with enhanced diagnostics and monitoring
Replaceable switching module for easier maintenance
Front-accessible control connections
Suitable for high-current industrial power switching
Industrial power distribution
High-current load switching
Motor and electrical equipment control
Industrial automation systems
Large machinery
High-power electrical panels
Heating and resistive load applications
Verify the application category and load current before installation.
The 700 A rating is for AC-1 applications; do not assume it is the AC-3 motor rating.
Verify the 48–130 V AC/DC control voltage before energizing the coil.
Use appropriate short-circuit protection and conductor sizing.
Follow Schneider Electric installation and tightening-torque requirements.
Disconnect power before installation or maintenance.
