SCHNEIDER LC1D32M7 Contactor

Product Overview

SCHNEIDER LC1D32M7 is a TeSys D / TeSys Deca IEC contactor designed for motor control and industrial switching applications. It is a 3-pole contactor with a 220V AC 50/60Hz coil, suitable for controlling motors, heating systems, pumps, fans, and industrial automation equipment.

This model provides 32A AC-3 rated current, 3 normally open main contacts (3NO), and supports applications up to 690V AC in industrial control systems.

Specifications

• Brand: SCHNEIDER ELECTRIC
• Series: TeSys D / TeSys Deca
• Model: LC1D32M7
• Product Type: AC Contactor
• Application: Motor Control / Power Switching
• Number of Poles: 3P
• Main Contacts: 3NO (Normally Open)
• Rated Operational Current:
  • AC-3: 32 A at ≤440 V AC
  • AC-1: 50 A at ≤440 V AC
• Rated Operational Voltage:
  • Up to 690 V AC
  • Up to 300 V DC
• Coil Voltage: 220 V AC
• Coil Frequency: 50/60 Hz
• Utilization Category: AC-1, AC-3, AC-3e, AC-4
• Motor Power Rating:
  • 7.5 kW at 220–230 V AC
  • 15 kW at 380–440 V AC
  • 18.5 kW at 500–690 V AC
• Auxiliary Contacts: 1NO + 1NC
• Mounting:
  • 35 mm DIN rail mounting
  • Panel mounting
• Connection Type: Screw clamp terminals
• Protection Rating: IP20
• Dimensions: Approx. 45 × 85 × 92 mm
• Weight: Approx. 0.375 kg

Advantages & Features

• Original Schneider TeSys D series contactor
• Reliable switching for industrial loads
• High mechanical and electrical durability
• Suitable for frequent motor starting and stopping
• Compact design for control cabinets
• Compatible with Schneider TeSys overload relays
• Supports various industrial automation applications
• Easy DIN rail installation and maintenance

Applications

• Industrial motor starters
• Pumps and compressors
• HVAC equipment
• Conveyor systems
• Machine tools
• Factory automation systems
• Control panels
• Electrical distribution equipment

Precautions

• Confirm coil voltage before energizing (220VAC 50/60Hz)
• Verify motor rated current before selection
• Use appropriate overload protection
• Check terminal wiring carefully
• Do not exceed rated current and voltage
• Disconnect power before installation or maintenance
