SCHNEIDER LAD-7B106 Auxiliary Contact Block

Product Overview
The SCHNEIDER LAD7B106 is a TeSys LRD accessory terminal block/adapter used for motor starter and thermal overload relay assemblies. It is designed to provide secure electrical connection and separate mounting between overload relays and contactors in industrial motor control systems.

Specifications

• Brand: Schneider Electric
• Model: LAD7B106
• Series: TeSys LRD
• Product Type: Auxiliary terminal block / adapter
• Function: Connection accessory for motor starters
• Compatible Devices: LRD01 to LRD35, LR3D01 to LR3D35 overload relays
• Mounting: 35 mm DIN rail or panel mounting
• Connection Type: Screw clamp terminals
• Material: Industrial-grade insulating housing
• Application Standard: Motor control and protection systems

Advantages & Features

• Stable and secure wiring connection
• Easy DIN rail or panel installation
• Compatible with TeSys motor control systems
• Compact design saves panel space
• Improves wiring organization and maintenance efficiency
• High reliability for industrial environments

Applications

• Motor control centers (MCC)
• Pump and fan control systems
• Industrial automation panels
• Compressor control systems
• Power distribution and protection systems
• Manufacturing machinery

Precautions

• Install only on compatible TeSys LRD systems
• Ensure power is OFF before installation or wiring
• Tighten screw terminals properly to avoid loose connections
• Avoid moisture, oil, and high-temperature environments
• Use correct matched relay and contactor combinations
