SCHNEIDER ILM62DB4A000 Servo Drive
Item NO.:
ILM62DB4A000Payment:
T/TPrice:
$650Product Origin:
JapanColor:
NEWProduct weight:
0.21KGLead Time:
In stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
Only part of the brand and model, if you have other product needs, please contact us.
The SCHNEIDER ILM62DB4A000 is a Lexium 62 ILM Distribution Box designed to connect multiple Lexium 62 ILM integrated servo drives or daisy-chain lines. It provides distribution of the DC bus, 24 VDC control power, and SERCOS III communication.
| Specification | Details |
|---|---|
| Brand | Schneider Electric |
| Model | ILM62DB4A000 |
| Product Type | Lexium 62 ILM Distribution Box |
| Input | 1 |
| Outputs | 4 |
| Input Current | 20 A |
| Output Current | 20 A |
| DC Bus Input Voltage | 250–700 VDC |
| DC Bus Output Voltage | 250–700 VDC |
| Control Voltage | 24 VDC (-20% to +25%) |
| Inverter Enable Input | 24 VDC |
| Inverter Enable Output | 40 VAC |
| Inverter Enable Output Current | 2 A |
| Communication | SERCOS III |
| Communication Speed | 100 Mbps |
| Protection Rating | IP65 |
| Cooling | Natural convection |
| Housing Material | Polycarbonate |
| Dimensions (W × D × H) | 230 × 151.4 × 94 mm |
| Weight | Approx. 0.85 kg |
