Schneider ILM0702P01F0000 Integrated Servo Motor

Basic Series Overview

Core Technical Specifications

1. Electrical Parameters

• Rated power: 720W (0.72kW)
• Max speed: 6000 rpm
• Rated torque: 1.15 Nm; Continuous stall torque: 1.7 Nm; Peak torque: 7.6 Nm
• Supply voltage: 250–700 VDC bus voltage
• Continuous stall current: 2.5 A, rated operating current: 1.5 A
• 6-pole dual stator stack structure, natural air cooling

2. Encoder & Brake

• Single-turn SinCos Hiperface absolute encoder (128 periods/rev), high positioning accuracy
• Built-in electromagnetic holding brake for vertical axis anti-drop protection
• Smooth plain shaft, shaft size: Φ11mm × 23mm length

3. Mechanical & Protection

• Mounting: Standard 70×70mm square flange, centering collar Φ60mm, mounting hole pitch 82mm
• Overall length: 252mm, net weight: 3.7kg
• Protection grade: IP54 for motor body
• Operating temperature range: Max 80°C winding temperature

Key Advantages

1. Integrated drive-motor design, greatly reduces cabinet wiring and space occupation
2. High peak torque ratio, excellent dynamic response for fast start-stop and frequent reciprocating motion
3. Absolute encoder, no homing required after power restart, improves production efficiency
4. Built-in brake optional, safe for vertical lifting axes
5. Compatible with PacDrive 3 motion control platform, supports multi-axis synchronous, electronic cam, flying shear functions
6. Stable operation in workshop dust, low vibration environment

Typical Application Scenarios

• Packaging machinery: Filling, labeling, cartoning, wrapping equipment
• Material handling: Linear conveyors, positioning slides, small lifting mechanisms
• Printing & textile equipment
• Automated assembly equipment, pick-and-place manipulators
• High-precision positioning automation production lines
