Schneider HMISTO511 HMI Touch Panel

Schneider HMISTO511 Harmony STO HMI Touch Panel

Product Description

The Schneider Electric HMISTO511 is a Harmony STO & STU series HMI touch panel designed for machine operator interface applications. It provides a compact touchscreen solution for monitoring, control, and visualization of industrial automation systems. It uses Vijeo Designer software for screen configuration and supports multiple PLC communication protocols.

Technical Specifications

• Brand: Schneider Electric
• Model: HMISTO511
• Product Type: HMI Touch Panel
• Series: Harmony STO & STU / Magelis
• Display Size: 3.4 inch
• Display Type: Monochrome STN LCD (Green/Orange/Red backlight)
• Resolution: 200 × 80 pixels
• Touch Type: Analog resistive touchscreen
• Processor: RISC CPU
• Processor Frequency: 333 MHz
• Supply Voltage: 24 V DC
• Power Consumption: Approx. 5 W
• Memory:
  • Application memory: 16 MB
  • Backup memory: 128 kB
• Communication Protocols:
  • Modbus
  • Uni-TE
  • Third-party protocols
• Programming Software: Vijeo Designer
• Protection Rating: IP65 front panel (when installed correctly)
• Mounting: Panel mounting

Advantages & Features

• Compact 3.4-inch touchscreen design saves cabinet space
• Clear industrial process monitoring and control interface
• Supports multiple PLC communication protocols
• Easy configuration with Vijeo Designer software
• Reliable operation in industrial environments
• Low power consumption and stable performance
• Suitable for machine-level operator control applications

Applications

• Industrial automation equipment
• Machine control systems
• Packaging machinery
• Production lines
• Process monitoring systems
• OEM automation equipment
• Factory control panels

Notes / Precautions

• Confirm PLC communication compatibility before installation
• Ensure correct 24 V DC power supply
• Use suitable communication cables and settings
• Protect the display from strong impact and chemicals
• Configure HMI projects using compatible software
• Verify panel mounting conditions before operation
• This model has been discontinued; replacement models include HMISTO715 and HMISTU655.
