Product Description

The SCHNEIDER HMIG5U2 is a Harmony GTU Open Box HMI Base Unit designed for industrial automation visualization and machine control applications. It works with Schneider HMIDT display modules to create a complete HMI terminal, providing operator interface, data monitoring, equipment control, and industrial communication functions.

Technical Specifications

• Brand: Schneider Electric
• Model: HMIG5U2
• Product Type: HMI Base Unit / Open Box Terminal
• Series: Harmony GTU
• Display Compatibility: Schneider HMIDT series Smart Display modules
• Power Supply: 12–24 VDC
• Processor: Intel X86
• Memory: 2 GB RAM
• Storage: 32 GB CFast card
• Ethernet Interface: 10BASE-T / 100BASE-TX / 1000BASE-T
• Ethernet Ports: 2 × RJ45
• Serial Communication:
  • COM1: RS-485
  • COM2: RS-232C / RS-422 / RS-485
• USB Interface: USB 2.0 ports
• Video Output: DVI-D
• Communication Protocols: Modbus, Modbus TCP/IP, Uni-Telway
• Operating System: Windows Embedded Standard 7

Advantages & Features

• High-performance industrial HMI platform
• Supports large-screen operator interfaces
• Flexible combination with different HMIDT display sizes
• Gigabit Ethernet communication capability
• Supports multiple industrial communication protocols
• Compatible with Schneider Vijeo Designer Runtime software
• Suitable for complex automation visualization applications
• Reliable design for industrial environments

Applications

• Industrial machine operation panels
• Factory automation systems
• Production line monitoring
• Process control systems
• PLC operator interfaces
• SCADA visualization terminals
• Equipment diagnostics and maintenance systems

Notes / Precautions

• HMIG5U2 is the HMI base unit, and requires a compatible HMIDT display module to form a complete HMI terminal.
• Confirm display size and software compatibility before replacement.
• Verify 12–24 VDC power supply requirements.
• Ensure communication settings match the connected PLC/controller.
