Product Description

The SCHNEIDER HMIDT732 is a Harmony GTU 15-inch touchscreen display module designed for Schneider Electric industrial HMI systems. It is used together with Harmony GTU Open Box HMIG5U/HMIGTU base units to provide operator visualization, machine control, monitoring, and industrial communication functions.

Technical Specifications

• Brand: Schneider Electric
• Model: HMIDT732
• Product Type: HMI Touchscreen Display Terminal
• Series: Harmony GTU / Magelis GTU
• Display Size: 15 inch
• Display Type: Color TFT LCD
• Resolution: 1024 × 768 pixels (XGA)
• Display Colors: 16 million colors
• Touch Panel: Analog resistive multi-touch
• Rated Voltage: 12–24 VDC
• Power Consumption: Approx. 22 W
• Communication Interfaces: USB 2.0 Type A / Mini B
• Protection Rating: IP66/IP67 front panel protection
• Installation: Indoor panel mounting
• Cooling Method: Natural convection
• Weight: Approx. 4.5 kg

Advantages & Features

• High-resolution 15-inch industrial touchscreen display
• Modular design for easy replacement and maintenance
• Compatible with Schneider Harmony GTU open box HMI systems
• Supports intuitive machine operation and visualization
• Durable industrial design with front panel protection
• Long backlight service life
• Suitable for complex automation monitoring applications

Applications

• Industrial machine operation panels
• Factory automation systems
• PLC operator interfaces
• Production line monitoring
• Process control systems
• SCADA visualization terminals
• Equipment diagnostics and maintenance systems

Notes / Precautions

• HMIDT732 is a display module, not a complete standalone HMI controller.
• Requires a compatible Harmony GTU base unit for full operation.
• Confirm mounting dimensions and system compatibility before replacement.
• Check power supply requirements (12–24VDC) before installation.
