SCHNEIDER GV2-ME08 Motor Circuit Breaker

SCHNEIDER GV2-ME08 Motor Circuit Breaker

Product Description
Schneider Electric GV2-ME08 is a TeSys GV2 thermal-magnetic motor circuit breaker designed for three-phase motor protection applications. It provides reliable protection against overload, short circuit, and phase failure, with adjustable thermal protection suitable for small industrial motors.

Technical Parameters

• Brand: Schneider Electric
• Model: GV2-ME08
• Product Type: Motor Circuit Breaker / Motor Protector
• Series: TeSys GV2
• Protection Type: Thermal-magnetic protection
• Number of Poles: 3P
• Rated Current: 4A
• Thermal Adjustment Range: 2.5…4A
• Rated Voltage: Up to 690V AC 50/60Hz
• Magnetic Trip: Approx. 13 × In
• Control Type: Push-button (Start/Stop)
• Terminal Type: Screw clamp terminals
• Mounting: 35mm DIN rail / panel mounting
• Application Category: AC-3 motor applications
• Standard: IEC 60947-2 / IEC 60947-4-1

Advantages & Features

• Original Schneider Electric TeSys GV2 motor protection device
• Integrated thermal and magnetic protection
• Protects motors from overload, short circuit, and phase loss
• Adjustable current setting for different motor ratings
• Compact design saves control cabinet space
• Easy DIN rail installation
• High mechanical durability and reliable operation
• Suitable for direct motor starting applications

Applications

• Industrial motor control systems
• Pumps and fans
• Conveyor systems
• Machine tools
• Packaging equipment
• Factory automation systems
• Motor starter cabinets
• Low-voltage electrical control panels

Notes

• Confirm motor rated current before installation.
• Adjust the thermal protection setting according to motor specifications.
• Check voltage, wiring, and load requirements before operation.
• Disconnect power before installation or maintenance.
• Use compatible contactors and accessories for complete motor starter solutions.
