Schneider GC4020M5 Contactor

Schneider GC4020M5 TeSys GC Modular Contactor

Product Description

The Schneider Electric GC4020M5 is a TeSys GC modular contactor designed for switching and controlling electrical loads such as motors, lighting, and heating equipment. It features a compact DIN rail mounting design, 2-pole normally open contacts, and a 220–240 V AC coil for reliable industrial and commercial control applications.

Technical Specifications

• Brand: Schneider Electric
• Model: GC4020M5
• Product Type: Modular Contactor
• Series: TeSys GC
• Application:
  • Motor control
  • Lighting control
  • Heating control
• Number of Poles: 2P
• Contact Configuration: 2 NO (Normally Open)
• Rated Operational Current:
  • 40 A (AC-7A)
  • 15 A (AC-7B)
• Coil Voltage: 220–240 V AC, 50 Hz
• Rated Insulation Voltage: 500 V AC
• Rated Impulse Withstand Voltage: 4 kV
• Mounting: DIN rail / clip-on mounting
• Electrical Durability: Up to 100,000 cycles
• Protection Rating: IP20
• Width: 36 mm
• Weight: Approx. 0.23 kg

Advantages & Features

• Compact modular design saves installation space
• Reliable switching performance for electrical loads
• Supports motor, lighting, and heating applications
• Easy DIN rail installation
• Long electrical service life
• Stable operation in industrial control cabinets
• Suitable for modular distribution panels

Applications

• Industrial control cabinets
• Motor switching systems
• Building automation
• Lighting control systems
• Heating control equipment
• Factory automation systems
• Electrical distribution panels

Notes / Precautions

• Verify coil voltage before installation
• Confirm load current and contact rating requirements
• Ensure correct DIN rail mounting
• Tighten terminals according to specifications
• Disconnect power before maintenance
• Use suitable protection devices for connected loads
