SCHNEIDER BMXAMI0800 Modicon X80 Analog Input Module
Item NO.:
BMXAMI0800Payment:
T/TPrice:
$650Product Origin:
JapanColor:
NEWProduct weight:
0.21KGLead Time:
In stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
Only part of the brand and model, if you have other product needs, please contact us.
The Schneider Electric BMXAMI0800 is an 8-channel, high-speed analog input module for the Modicon X80 platform. It receives voltage and current signals from industrial sensors and transmitters, converting them into digital data for PLC monitoring and process control. Its input channels are non-isolated.
|
Parameter |
Specification |
|---|---|
|
Brand |
Schneider Electric |
|
Model |
BMXAMI0800 |
|
Product Series |
Modicon X80 |
|
Product Type |
Analog Input Module |
|
Number of Inputs |
8 |
|
Input Signals |
Voltage and current |
|
Current Ranges |
±20 mA, 0–20 mA, 4–20 mA |
|
Voltage Ranges |
±10 V, ±5 V, 0–10 V, 0–5 V, 1–5 V |
|
A/D Conversion |
16-bit |
|
Input Resolution |
15 bits + sign |
|
Channel Isolation |
Non-isolated |
|
Current Input Impedance |
250 Ω |
|
Voltage Input Impedance |
10 MΩ |
|
Nominal Conversion Cycle |
9 ms for 8 channels |
|
Power Consumption |
Approx. 1.04 W at 24 V DC |
|
Electrical Connection |
28-way connector |
|
Protection Rating |
IP20 |
|
Operating Temperature |
0–60°C |
|
Mounting |
Modicon X80 PLC rack |
Eight configurable analog input channels.
Supports common industrial voltage and current signals.
High-speed data acquisition for process monitoring.
16-bit analog-to-digital conversion.
Compact design for Modicon X80 automation systems.
Industrial process monitoring
Pressure, flow, and level measurement
Sensor and transmitter signal acquisition
Manufacturing and production automation
PLC-based control systems
Confirm compatibility with the Modicon M340 or M580 system configuration.
Configure each channel according to its voltage or current input range.
Because the channels are non-isolated, verify grounding and signal common requirements.
Confirm the correct 28-way terminal connector and field wiring before installation.
