Schneider BLRCH344A413B52 VarPlusCan HDuty Power Factor Correction Capacitor

Overview

Core Electrical Specifications

• Model No.: BLRCH344A413B52
• Rated voltage: 525V AC 50/60Hz
• Reactive power:
  • 34.4 kvar @ 50Hz
  • 41.3 kvar @ 60Hz
• 3-phase integrated structure
• Dielectric loss: ＜0.2 W/kvar; Total power loss: ＜0.5 W/kvar
• Capacitance tolerance: -5% ~ +10%
• Overload capacity: Continuous 1.8× rated current; withstand 1.1× rated voltage for 8h daily
• Inrush current peak: Up to 250× nominal current
• Max annual switching cycles: 7000 times
• Service life: 130,000 hours
• Harmonic tolerance: Grid harmonic distortion ≤20%

Mechanical & Environmental Parameters

• Dielectric: Self-healing metallized Zn-Al polypropylene film
• Impregnation: Non-PCB dry biodegradable PUR resin
• Protection grade: IP20 indoor cabinet installation
• Mounting: Vertical / horizontal dual installation mode, single-point fixing & earthing
• Terminal: ClampTite anti-loose bolt terminals, finger-safe design
• Operating temperature: -25℃ ~ +55℃, temperature class D
• Compliance standard: IEC 60831-1, IEC 60831-2

Key Safety & Performance Features

1. Self-healing technology

   Minor dielectric breakdown automatically repairs, avoids capacitor short-circuit failure.
2. Overpressure disconnector safety device

   Internal pressure rise triggers mechanical disconnection to isolate fault and prevent explosion risk.
3. Built-in discharge resistors

   Quickly release residual voltage after power-off for maintenance safety.
4. Heavy-duty anti-harmonic design

   Enhanced current carrying capacity, matches detuned reactor APFC panels with high harmonic loads.
5. Low heat loss, stable long-term operation

   Low dielectric loss reduces cabinet temperature rise, extending whole compensation cabinet service life.
