Schneider ABL7RE2402 Power Supply

Schneider ABL7RE2402 Power Supply (Phaseo 24VDC SMPS)

The Schneider ABL7RE2402 is a Phaseo industrial switching power supply (SMPS) used to convert AC input power into stable 24V DC control voltage for PLCs, sensors, relays, and automation equipment.

Product Information

• Brand: Schneider Electric
• Series: Phaseo ABL7RE
• Model: ABL7RE2402
• Type: Industrial DC Power Supply (SMPS)
• Output voltage: 24 VDC
• Output current: 2 A
• Output power: 48 W
• Input voltage: 100–240 VAC (wide range)
• Function: Stable DC power for control circuits
• Mounting: DIN rail installation

What it actually is

This is a power supply unit, not a control or logic device.

It is used to:

• Convert AC → 24V DC
• Provide stable control voltage for automation systems
• Power PLCs, HMI panels, sensors, relays, and communication modules

It does NOT:

• Control machines ❌
• Process signals ❌
• Act as PLC or module ❌

System Role (Simple)

AC mains power (110/220V)
→ ABL7RE2402 power supply
→ 24V DC output
→ PLC / HMI / sensors / relays / I/O modules

So it acts like a “power source for control systems.”

Key Features

• Wide input range (100–240 VAC)
• Stable regulated 24V DC output
• 2A output current (48W)
• Built-in protections:
  • Overload protection
  • Short circuit protection
  • Overvoltage / undervoltage protection
• LED status indicator
• DIN rail mounting for control panels

Typical Applications

• PLC control cabinets
• Industrial automation systems
• HMI panels and operator stations
• Sensor and instrumentation power
• Relay and control circuit supply
• Machine electrical panels

Advantages

• Stable DC voltage output
• High efficiency switching design
• Compact DIN rail installation
• Wide AC input compatibility (global use)
• Reliable industrial-grade power supply

Important Notes

• Not a PLC ❌
• Not a relay ❌
• Not a drive ❌
• Not a communication module ❌
• It is a 24V DC industrial switching power supply ✔

Precautions

• Do not exceed 2A output load
• Ensure proper ventilation in cabinet
• Correct AC wiring is required (L / N / PE grounding)
• Avoid overload or short circuit on output terminals
• Must be installed by qualified technician
