SCHNEIDER A9F94216 Miniature Circuit Breaker

SCHNEIDER A9F94216 Miniature Circuit Breaker

Product Overview

The Schneider Electric A9F94216 is an Acti9 iC60L Miniature Circuit Breaker (MCB) designed to provide protection against overload and short-circuit faults in low-voltage electrical distribution systems. It features a 2-pole, 16A rated current, C curve thermal-magnetic trip characteristic, suitable for industrial control panels, automation cabinets, and power distribution applications.

Main Specifications

• Manufacturer: Schneider Electric
• Model: A9F94216
• Product Type: Miniature Circuit Breaker (MCB)
• Series: Acti9 iC60L
• Poles:
  • 2P (2 Pole)
• Rated Current:
  • 16 A
• Trip Curve:
  • C Curve
• Rated Voltage:
  • 230/400 VAC
• Frequency:
  • 50/60 Hz
• Tripping Technology:
  • Thermal-magnetic
• Breaking Capacity:
  • 15 kA (IEC/EN 60898-1)
  • Up to 25 kA (IEC/EN 60947-2, depending on conditions)
• Mounting:
  • 35 mm DIN rail mounting
• Protection Functions:
  • Overload protection
  • Short-circuit protection

Advantages & Features

• High breaking capacity for industrial protection applications
• Reliable thermal-magnetic protection mechanism
• C curve characteristic suitable for general industrial loads
• Compact modular design saves control cabinet space
• Supports auxiliary accessories and remote monitoring options
• VisiTrip fault indication helps identify tripped circuits quickly
• VisiSafe technology improves operating safety
• Long mechanical and electrical service life

Applications

• Industrial control cabinets
• PLC automation systems
• Machine power circuits
• Factory electrical distribution
• Motor control auxiliary circuits
• Building and commercial power distribution
• Industrial equipment protection

Important Notes

• Confirm rated current and trip curve before replacement.
• This MCB provides overload and short-circuit protection only; it does not provide residual current protection.
• Ensure correct voltage rating before installation.
• Install on standard DIN rail.
• Disconnect power before wiring or maintenance.
