SCHNEIDER 9070T50D1 Control Transformer

SCHNEIDER 9070T50D1 Control Transformer

Product Overview

The Schneider Electric 9070T50D1 is a Type T Industrial Control Transformer designed to provide stable low-voltage control power for industrial automation equipment. It converts higher supply voltages into a reliable control voltage, commonly used for powering contactors, relays, PLC control circuits, and other electrical control components.

Main Specifications

• Manufacturer: Schneider Electric / Square D
• Model: 9070T50D1
• Product Type: Industrial Control Transformer
• Series: Type T (Class 9070)
• Rated Power:
  • 50 VA
• Phase:
  • Single Phase (1P)
• Primary Voltage:
  • 220/240/480 VAC (multiple taps)
  • 440/460/480 VAC depending on connection
• Secondary Voltage:
  • 110/115/120 VAC
• Frequency:
  • 50/60 Hz
• Temperature Rise:
  • 55°C
• Connection:
  • Screw clamp terminals
• Insulation Temperature:
  • 105°C
• Mounting:
  • Panel mounting
• Certifications:
  • UL Listed
  • CSA Certified

Advantages & Features

• Provides reliable control voltage for industrial systems
• High voltage regulation performance under load changes
• Compact design for control cabinet installation
• Copper winding construction for improved efficiency
• Suitable for continuous industrial operation
• Compatible with Schneider industrial control components
• Meets UL/CSA industrial safety requirements

Applications

• Industrial control panels
• PLC control circuits
• Motor starter systems
• Contactors and relay power supplies
• Machine automation equipment
• Factory electrical cabinets
• Industrial production lines

Important Notes

• Confirm primary and secondary voltage wiring before installation.
• Ensure the connected load does not exceed the 50 VA rated capacity.
• Use appropriate fusing/protection according to application requirements.
• Disconnect power before wiring or replacement.
• This is a control transformer, not a power distribution transformer.
