Rhino PSP24-240S Power Supply

Rhino PSP24-240S Power Supply

Product Description

The Rhino PSP24-240S is a DIN rail mounted switching power supply from the RHINO SELECT PSP series. It converts AC input power into a stable 24 VDC output and is designed for industrial control panels, PLC systems, sensors, and automation equipment. The unit provides 240 W output power with 10 A current capacity and supports both DIN rail and chassis mounting.

Technical Specifications

• Brand: RHINO (AutomationDirect)
• Model: PSP24-240S
• Product Type: Switching Power Supply
• Series: RHINO SELECT PSP
• Input Voltage:
  • 120 VAC / 240 VAC nominal
  • 85–132 VAC / 187–264 VAC range
• Input Phase: Single phase
• Output Voltage: 24 VDC (adjustable)
• Output Current: 10 A
• Output Power: 240 W
• Output Adjustment Range: 24–28 VDC
• Efficiency:
  • Approx. 82% at 115 VAC
  • Approx. 85% at 230 VAC
• Mounting: 35 mm DIN rail or chassis mounting
• Housing: Plastic enclosed design
• Terminal Type: Removable screw terminal
• Protection Functions:
  • Overvoltage protection
  • Short-circuit protection
  • Overload protection
• Protection Rating: IP20
• Operating Temperature: -10°C to +70°C

Advantages & Features

• Provides stable 24 VDC power for industrial control systems
• High 10 A output capacity suitable for PLC and automation loads
• Compact DIN rail design saves cabinet space
• Supports wide AC input range
• Built-in overload and short-circuit protection improves system safety
• Adjustable output voltage for flexible applications
• Suitable for continuous industrial operation

Applications

• PLC control cabinets
• Industrial automation systems
• Sensors and actuators
• HMI panels
• Machine control equipment
• Factory automation systems
• Instrumentation and control systems

Notes / Precautions

• Verify AC input voltage before installation
• Ensure total load current does not exceed 10 A
• Maintain proper ventilation inside control cabinets
• Confirm polarity when connecting DC output
• Use appropriate circuit protection devices
