Rexroth VMA 035 BR 001-D Hydraulic Motor / Supply Module





Product Overview

The Bosch Rexroth VMA 035 BR 001-D is NOT a hydraulic motor. It is actually a Servodyn VM series power supply / DC link module used in Rexroth Indramat servo drive systems.

It is typically used in:

• Indramat Servodyn systems
• Multi-axis servo drive cabinets
• CNC and industrial motion control systems

Key Specifications

• Brand: Bosch Rexroth (Indramat)
• Model: VMA 035 BR 001-D
• Material No.: 1070085679
• Series: VM / Servodyn-D supply module
• Type: DC power supply / servo drive supply unit

Electrical Data

• Input Voltage: 3-phase 400–460 VAC
• Frequency: 50/60 Hz
• DC Output Link: ~670 V DC regulated
• Rated Current: ~35 A mains current at 45°C
• Power Rating: ~24 kVA at 45°C
• Peak Power: up to ~34.6 kVA
• Module Width: 100 mm
• Weight: approx. 11.1 kg

Function Principle

This module works as a central power unit in servo systems:

• Converts AC input → stable DC link (≈670V)
• Feeds multiple servo drive amplifiers
• Supports energy recovery (regenerative braking)
• Stabilizes motion system power supply

It is a system-level power backbone, not a motor.

Advantages & Features

• Stable DC bus power for multi-axis servo systems
• Supports regenerative energy feedback
• Compact rack module design (100 mm width)
• High reliability for continuous industrial operation
• Designed for CNC and automation systems
• Modular integration in Indramat drive cabinets

Applications

• CNC machine tools
• Industrial automation systems
• Servo multi-axis control cabinets
• Robotics systems
• Printing and packaging machinery
• Legacy Indramat / Rexroth Servodyn systems

Precautions

• Must be used only in Rexroth Servodyn / VM system architecture
• Dangerous high voltage (≈670V DC bus)
• Incorrect wiring may damage entire drive system
• Requires proper cooling and cabinet ventilation
• Not compatible with modern standalone VFD systems
• Installation only by qualified engineers
