REXROTH R911347306 / INDRADRIVE MI KSM02.1 SET 01 Servo Drive

REXROTH R911347306 / INDRADRIVE MI KSM02.1 SET 01 Servo Drive

Product Overview

• Brand: Bosch Rexroth / Indramat

• Model: INDRADRIVE MI KSM02.1 SET 01

• Part Number: R911347306

• Product Type: Motor-Integrated Servo Drive

• Series: IndraDrive Mi KSM02.1

• Design: Synchronous servo motor with integrated inverter, control electronics and firmware

• Protection: IP65

• Cooling: Self-cooling / convection through motor housing

Key Technical Specifications

• DC Bus Voltage: 540–750 VDC

• Power Range: 0.4–1.2 kW

• Continuous Torque Range: 2.2–10.5 Nm

• Maximum Torque Range: 9.4–35 Nm

• Communication: Multi-Ethernet

• Maximum Speed: Configuration-dependent

• Drive Type: Distributed / motor-integrated servo drive

Advantages & Features

• Integrated motor, inverter and control electronics

• Compact distributed-drive architecture

• IP65 protection for machine-mounted applications

• Hybrid cable provides DC power and communication

• Efficient convection cooling

• Designed for precise multi-axis motion control

Applications

• Industrial automation

• Packaging machinery

• Machine tools

• Material handling

• Robotics and motion-control systems

• Distributed multi-axis servo systems

Important Notes

• R911347306 is a specific configuration within the KSM02.1 family.

• Verify the complete type code and electrical configuration before installation.

• Use compatible Rexroth KCU/KSM components and approved cabling.

• High-voltage DC-bus equipment should only be installed and serviced by qualified personnel.
