Rexroth R161924282 Linear Guide Component

Rexroth R161924282 Linear Guide Component

Rexroth R161924282 Linear Guide Component

  • Item NO.:

    R161924282
  • Payment:

    T/T
  • Price:

    $1950
  • Product Origin:

    Germany
  • Color:

    NEW
  • Product weight:

    1.51KG
  • Lead Time:

    in stock

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

  •
    • Bosch Rexroth R161924282 Linear Guide Component (HK 2505 KR – Manual Clamping Element)



      The Rexroth R161924282 is not a moving guide rail itself, but a manual clamping / locking element used on linear guide rail systems (ball/roller rail systems).


      Product Information

      • Brand: Bosch Rexroth (Germany)
      • Part number: R161924282
      • Type: Manual clamping element (brake / lock unit)
      • Series: HK 2505 KR
      • Function: Mechanical locking of linear guide carriage
      • System: Profile rail linear motion system (HIWIN/THK-compatible class)

      What it actually is

      This part is used to lock a linear guide carriage in position, meaning:

      • Stops movement on linear rail
      • Holds position under load
      • Manual lever clamping (no electricity needed)
      • Used for positioning, maintenance, or safety locking




      System Role (Simple)

      Linear guide rail + carriage
      R161924282 clamping unit (this part)
      → locks carriage in fixed position
      → prevents movement under force

      So it acts like a “mechanical brake for linear motion systems.”


      Key Features

      • Manual operation (no power required)
      • High holding force (~1200–2000 N class depending condition)
      • Compatible with SNS ball/roller guide rails
      • Adjustable lever position
      • Compact industrial design
      • Long service life (hundreds of thousands of cycles)

      Typical Applications

      • CNC machine tool positioning
      • Industrial automation slides
      • Assembly stations
      • Linear positioning systems
      • Safety locking during maintenance
      • Precision mechanical fixtures

      Advantages

      • Simple mechanical design (very reliable)
      • No electrical or pneumatic supply needed
      • Strong holding force for positioning
      • Easy integration into Rexroth linear systems
      • Long operational lifespan

      Important Notes

      • Not a PLC module ❌
      • Not a sensor ❌
      • Not a motor ❌
      • Not a guide rail ❌
      • It is a manual clamping / locking accessory for linear motion systems

      Precautions

      • Must match correct rail size (size 25 system)
      • Must be mounted properly to avoid misalignment
      • Do not exceed rated holding force
      • Requires periodic inspection for wear
      • Only works with compatible linear guide profiles

The structure and details of the product:



Please make an inquiry for more models
