REXROTH KHZ-DA-032-0010-O 0822010541 Hydraulic Valve

Product Overview

Model: KHZ-DA-032-0010-O
Part Number: 0822010541
Manufacturer: Bosch Rexroth / AVENTICS

Note: This model is not a hydraulic valve. The 0822010541 / KHZ-DA-032-0010-O is an AVENTICS KHZ Series Short-Stroke Pneumatic Cylinder (Compact Cylinder). It is a double-acting pneumatic actuator designed for short-stroke linear motion applications.

Technical Specifications

• Product Type: Short-Stroke Pneumatic Cylinder
• Series: AVENTICS KHZ Series
• Model: KHZ-DA-032-0010-O
• Part Number: 0822010541
• Cylinder Type: Double-acting cylinder
• Piston Diameter: 32 mm
• Stroke Length: 10 mm
• Operating Pressure: 0.6–10 bar
• Port Connection: G1/8
• Piston Rod Thread: M6 internal thread
• Cushioning: Elastic cushioning
• Piston Rod: Single-sided
• Medium: Compressed air
• Operating Temperature: Approx. -25°C to +80°C
• Mounting: Compact industrial installation
• Weight: Approx. 0.2 kg

Advantages & Features

• Compact Design
  Small size and short stroke design make it suitable for limited installation spaces.
• Fast Linear Motion
  Provides quick forward and backward movement for automation equipment.
• Double-Acting Operation
  Enables controlled movement in both extension and retraction directions.
• Reliable Industrial Performance
  Designed for continuous operation in pneumatic automation systems.
• Easy Installation
  Standard G1/8 ports and M6 rod thread simplify system integration.
• Low Maintenance
  Simple pneumatic structure provides long service life.

Applications

• Automated Assembly Equipment
• Packaging Machinery
• Material Handling Systems
• Pick-and-Place Devices
• Clamping Mechanisms
• Machine Tool Automation
• Pneumatic Control Systems

Precautions

• Confirm cylinder size, stroke length, and mounting requirements before installation.
• Use clean and filtered compressed air.
• Ensure operating pressure is within the rated range.
• Check air leakage and connection sealing regularly.
• Avoid side loads that may damage the piston rod.
• Lubrication and maintenance should follow system requirements.
