Rexroth HCS02.1E-W0070-A-03-NNNN Servo Drive

Product Overview
The Bosch Rexroth HCS02.1E-W0070-A-03-NNNN is an IndraDrive C HCS02 compact converter designed for single-axis servo and motion-control applications. It converts the incoming AC supply into a controlled variable-frequency/variable-voltage output for servo motor operation. The exact material number is R911298372.

Technical Specifications

• Model: HCS02.1E-W0070-A-03-NNNN
• Material No.: R911298372
• Series: IndraDrive C HCS02
• Type: Compact Converter / Servo Drive
• Power Range: 1.5–11 kW
• Mains Voltage: 3 × AC 200–500 V ±10%
• Continuous Current: 28.3 A
• Peak Current: 70.8 A
• Input Frequency: 50–60 Hz
• Output: 3-phase AC, variable voltage/frequency
• Maximum Output Frequency: Up to 1600 Hz depending on switching frequency
• Cooling: Internal air cooling with integrated blower
• Protection: IP20
• Control Voltage: 24 VDC
• Dimensions: Approx. 105 × 251.5 × 352 mm
• Weight: Approx. 7.5 kg

Advantages & Features

• Compact single-axis drive design
• High peak-current capability up to 70.8 A
• Integrated control section
• 2.5× overload capability
• Variable-speed and precision motion control
• Integrated braking/control functions
• Suitable for demanding industrial automation applications

Applications

• Servo motor control
• Machine tools
• Robotics and automation
• Packaging machinery
• Printing machinery
• Material handling systems
• Single-axis industrial motion control
