Rexroth CSH01.1C-SE-ENS-NNN-MEM-NN-S-NN-FW Control Section

Product Type: Advanced Control Section
Model: CSH01.1C-SE-ENS-NNN-MEM-NN-S-NN-FW
Material No.: R911309730
Series: IndraDrive CSH01.1C
Manufacturer: Bosch Rexroth / Indramat

The CSH01.1C-SE-ENS-NNN-MEM-NN-S-NN-FW is an Advanced Control Section for Bosch Rexroth IndraDrive servo systems. It is a plug-in control unit installed in a compatible IndraDrive power section and provides motion control, encoder evaluation, SERCOS communication and parameter/diagnostic functions. The exact configuration corresponds to SERCOS master communication, IndraDyn/Hiperface/1 Vpp/TTL encoder interface and encoder emulation.

Technical Specifications

The CSH01.1C is a configurable control section, and Bosch Rexroth's type-code documentation identifies SE as SERCOS, ENS as IndraDyn/Hiperface/1 Vpp/TTL encoder, and MEM as encoder emulation.

Advantages & Features

• Advanced Motion Control: Designed for high-performance IndraDrive servo applications.
• SERCOS Communication: Provides synchronized communication between the drive and higher-level automation controller.
• Flexible Encoder Support: ENS interface supports IndraDyn, Hiperface, 1 Vpp and TTL encoder systems.
• Encoder Emulation: MEM option provides an encoder-emulation interface for integration with external control systems.
• Integrated I/O: Supports configurable digital and analog signal processing.
• RS232 Interface: Convenient for commissioning, diagnostics and parameterization.
• Modular Design: Plug-in control section can be combined with compatible Rexroth power sections.
• Motion Logic Capability: IndraDrive control units can provide integrated motion-control and technology functions.

Typical Applications

• Industrial automation
• Servo motion control
• Machine tools
• Packaging machinery
• Printing machinery
• Material handling
• Assembly systems
• Food-processing machinery
• Production lines
• Multi-axis motion-control systems
