RELIANCE 57C430A PLC Module

RELIANCE 57C430A PLC Module

Product Description

The RELIANCE 57C430A is an AutoMax 6010 Processor Module manufactured by Reliance Electric. It is the central processing unit (CPU) module of the AutoMax PLC system, responsible for executing user application programs and controlling other modules installed in the AutoMax rack. The module is based on a Motorola 68010 16-bit microprocessor and is designed for industrial automation and drive control applications.

Technical Specifications

• Brand: Reliance Electric
• Model: 57C430A
• Product Type: PLC Processor Module / CPU Module
• Series: AutoMax 6010
• Processor: Motorola 68010 (16-bit CPU)
• CPU Speed: 8 MHz
• Memory: 256K Parity RAM
• Programming Languages:
  • Ladder Logic
  • BASIC
  • Control Block
• Communication Interface: RS-232C ports
• Rack Installation: AutoMax rack backplane
• Battery Backup: Lithium battery and super-capacitor for RAM retention
• Application: Industrial control and automation systems

Advantages & Features

• Original Reliance Electric AutoMax processor module
• Provides central control and program execution for AutoMax systems
• Reliable CPU performance for legacy industrial applications
• Supports multiple programming methods for flexible control development
• Battery-backed memory helps protect application data during power loss
• Suitable for replacement and maintenance of existing AutoMax installations

Applications

• Industrial automation systems
• Motor drive control systems
• Factory production equipment
• Process control systems
• Reliance AutoMax PLC installations
• Legacy DCS control applications

Notes / Precautions

• This is a PLC processor module, not a power drive module.
• Confirm compatibility with the existing AutoMax rack and system configuration before installation.
• Check battery condition and program backup before replacement.
• Handle carefully to avoid static damage to electronic components.
